RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting a Prepended Autonomous System Path Filter 451
Figure 503: Key Settings Form
1. AS Number Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
AS Number AS number.
5. Click Add to add the filter.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 5.19.4.5
Deleting a Prepended Autonomous System Path Filter
To delete a prepended autonomous system path filter from a BGP route map entry, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » filter » route-map » {name} » entry » {number} » set » as-path »
prepend, where {name} is the name of the route map and {number} is the entry number. The AS Path to
Prepend table appears.
Figure 504: AS Path to Prepend Table
1. Add Button 2. Edit Button 3. Delete Button
