RUGGEDCOM ROX II
User Guide
Chapter 3
Device Management
Viewing DNP Device Table Statistics 115
Section 3.20.4
Viewing DNP Device Table Statistics
To view the statistics collected for DNP device tables, navigate to interfaces » serial » dnp-device-table. The
DNP Device Table table appears.
Figure 117: DNP Device Table
1. Device Address 2. Remote IP 3. Serial Port
This table provides the following information:
Parameter Description
device-address The DNP device address.
remote-ip The IP address of the remote host that provides a connection to the this DNP device
address.
serial-port The target serial port.
Section 3.20.5
Clearing Serial Port Statistics
To clear the statistics collected for a specific serial port, do the following:
1. Navigate to interfaces » serial » port » {slot/port}, where {slot/port} is the slot name and port number of the
serial port.
2. Click clear-serial-port-statistics in the menu. The Trigger Action form appears.
