Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
114 Viewing Transport Connection Statistics
Figure 116: TCP/UDP Connection Statistics Form
1. Remote IP 2. Remote TCP/UDP Port 3. Local TCP/UDP Port 4. Transport 5. Rx-packets 6. Tx-packets 7. Target Port
8. Status
These tables and forms provide the following information:
Parameter Description
remote-ip The IP address of the remote serial server.
Remote TCP/UDP port The port of the remote serial server.
Local TCP/UDP port The local port for the incoming connection.
transport The transport protocol (UDP or TCP) for this serial port.
rx-packets The number of packets received from TCP/UDP.
tx-packets The number of packets transmitted to TCP/UDP.
target-port The target serial port.
status The connection status of the serial port.
