RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Configuring the Destination Zone 391
Section 5.17.11.4
Configuring the Destination Zone
To configure the destination zone for a firewall policy, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » {firewall} » fwpolicy{policy} » destintion-zone, where
{firewall} is the name of the firewall and {policy} is the name of the policy. The Destination Zone form
appears.
Figure 428: Destination Zone Form
1. Pre-Defined Zone List 2. All Check Box
3. Configure the following parameter(s) as required:
Parameter Description
predefined-zone
all
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.17.11.5
Deleting a Policy
To delete a policy, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » {firewall} » fwpolicy, where {firewall} is the name of the
firewall. The Main Policy Settings table appears.
