RUGGEDCOM ROX II
User Guide
Chapter 3
Device Management
Deleting a Domain Name Server 183
Figure 194: Key Settings Form
1. Address Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
address Synopsis: The ip-address type represents an IP address and is IP version neutral.
The format of the textual representations implies the IP version.
4. Click Add.
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
Section 3.26.2.3
Deleting a Domain Name Server
To delete a domain name server, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to admin » dns » server. The Domain Name Servers table appears.
Figure 195: Domain Name Servers Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen domain name server.
