Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
290 Managing NTP Broadcast/Multicast Addresses
Figure 301: Network Time Protocol (NTP) Servers Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen server.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.12.12
Managing NTP Broadcast/Multicast Addresses
When broadcast or multicast addresses for known NTP servers are configured, the NTP daemon monitors
advertisements from each address and chooses the server with the lowest stratum to use as the NTP host. This
is opposed to manually configuring a list of servers or peers.
The following sections describe how to configure and manage broadcast and multicast addresses for an NTP
server:
• Section 5.12.12.1, “Viewing a List of Broadcast/Multicast Addresses”
• Section 5.12.12.2, “Adding a Broadcast/Multicast Address”
• Section 5.12.12.3, “Deleting a Broadcast/Multicast Address”
Section 5.12.12.1
Viewing a List of Broadcast/Multicast Addresses
To view a list of broadcast/multicast addresses for an NTP server, navigate to services » time » ntp »
broadcast. If addresses have been configured, the NTP Broadcast/Multicast Servers table appears.
Figure 302: NTP Broadcast/Multicast Servers Table
