RUGGEDCOM ROX II
User Guide
Chapter 3
Device Management
Viewing the HSPA Network Status for Cellular Modems 143
Figure 147: PPP Interfaces Statistics Form
1. Status 2. Local IP Address 3. Peer IP Address 4. TX 5. RX 6. MTU
This table provides the following information:
Parameter Description
Status PPP connection status
Local IP address The IP address assigned to the modem by the remote server
Peer IP address The IP address of the remote server
TX (bytes) The bytes transmitted over the modem
RX (bytes) The bytes received by the modem
mtu MTU (Maximum Transmission Unit) value on the ppp interface
Section 3.23.4
Viewing the HSPA Network Status for Cellular Modems
To view the status of the HSPA GSM network for a cellular modem, navigate to interfaces » cellmodem » {slot/
port} {profile} » {profile}, where {slot/port} is the slot name and port number for the cellular modem, and {profile}
is the profile (e.g. hspa or hspaplus). The GSM/HSPA/HSPA+ Cellular Modem Information form appears.
