Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
798 Adding an IPv6 Network Prefix
Section 5.38.5.1
Adding an IPv6 Network Prefix
To add a network prefix to the neightbor discovery configuration for an IPv6 address, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to ip » {interface} » ipv6 » nd » prefix, where {interface} is the name of the routable interface.
3. Click <Add prefix>. The Key Settings form appears.
Figure 918: Key Settings Form
1. IPv6 Prefix Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
IPv6 Prefix The IPv6 network/prefix.
5. Click Add to add the network prefix. The Lifetime and Prefix forms appear.
Figure 919: Lifetime Form
1. Valid Lifetime Box 2. Preferred Lifetime Box
