Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
488 Adding a Network IP Address
Figure 553: Subnet Table
If no IP addresses have been configured, add addresses as needed. For more information, refer to
Section 5.20.5.2, “Adding a Network IP Address”.
Section 5.20.5.2
Adding a Network IP Address
To add an IP address for a RIP network, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » rip » network » ip and click <Add ip>. The Key Settings form appears.
Figure 554: Key Settings Form
1. Subnet Address/Prefix Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Subnet Address/Prefix The IPv4 network address and prefix.
4. Click Add to add the IP address.
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
Section 5.20.5.3
Deleting a Network IP Address
To delete an IP address from a RIP network, do the following:
