RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting an IPv4 Address 793
Figure 913: Key Settings Form
1. Address Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
IP Address The IPv4/Prefix (xxx.xxx.xxx.xxx/xx).
5. Click Add to create the new address. The Addresses form appears.
Figure 914: Addresses Form
1. Peer Box
6. Configure the following parameter(s) as required:
Parameter Description
peer The peer IPv4 Address (xxx.xxx.xxx.xxx, PPP, MLPPP, FrameRelay link only).
7. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
8. Click Exit Transaction or continue making changes.
Section 5.38.3.3
Deleting an IPv4 Address
To delete an IPv4 address for a routable interface, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
