Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
438 Viewing the Status of Dynamic BGP Routes
Parameter Description
Router ID Router ID for BGP.
5. Configure autonomous system path filters. For more information, refer to Section 5.19.6.3, “Adding an
Autonomous System Path Filter”.
6. Configure prefix list filters. For more information, refer to Section 5.19.5.3, “Adding a Prefix List”.
7. Configure route map filters. For more information, refer to Section 5.19.3.3, “Adding a Route Map Filter”.
8. Configure a network. For more information, refer to Section 5.19.8.2, “Adding a Network”.
9. Configure IP addresses for neighbors. For more information, refer to Section 5.19.7.2, “Adding a Neighbor”.
10. Configure aggregate addresses. For more information, refer to Section 5.19.9.2, “Adding an Aggregate
Address”.
11. Configure redistribution metrics. For more information, refer to Section 5.19.11.2, “Adding a Redistribution
Metric”.
12. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
13. Click Exit Transaction or continue making changes.
Section 5.19.2
Viewing the Status of Dynamic BGP Routes
To view the status of the dynamic BGP routes configured on the device, navigate to routing » status » bgp »
route. If BGP routes have been configured, the Route table appears.
Figure 484: Route Table
The Route table provides the following information:
Parameter Description
Network Network.
To view the routing information advertised to the network, navigate to routing » status » bgp » neighbor »
advertised-route. The Advertised Route table appears.
