Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
178 Deleting a Virtual Switch Interface
Figure 188: Key Settings Form
1. Interface Name Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
Interface Name Interface name.
5. Click Add to create the new interface. The new interface is now visible under the ip menu. The name of the
interface is the ID of the virtual switch preceded by vs (i.e. vs1, vs2, etc.)
6. Assign an IPv4 or IPv6 address to the interface. For more information, refer to Section 5.38.3.2, “Adding an
IPv4 Address” or Section 5.38.6.2, “Adding an IPv6 Address”.
7. If necessary, add one or more VLANs to the virtual switch interface. For more information, refer to
Section 5.35.7.2, “Adding a Virtual Switch VLAN”.
8. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
9. Click Exit Transaction or continue making changes.
Section 3.25.4.3
Deleting a Virtual Switch Interface
To delete a virtual switch interface, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to interface » virtualswitch » {id} » interface, where {id} is the ID assigned to the virtual switch.
The Interface table appears.
