Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
676 Deleting a Static ARP Table Entry
Parameter Description
MAC Default: 00:00:00:00:00:00
The MAC address of the network device specified by the IP address.
VLAN ID The VLAN Identifier of the VLAN upon which the MAC address operates.
status Synopsis: resolved, unresolved
Default: unresolved
Address Resolution Protocol (ARP) entry resolution status:
• Resolved: The MAC-IP address pair is resolved and operational.
• Unresolved: The device hasn't resolved the MAC-IP address pair and keeps sending
ARP requests periodically.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 5.31.3.3
Deleting a Static ARP Table Entry
To delete a static ARP table entry, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to switch » layer3-switching » arp-table. The ARP Table Configuration table appears.
Figure 794: ARP Table Configuration Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete button next to the chosen address.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
