RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding a Static ARP Table Entry 675
Figure 792: Key Settings Form
1. IP Address Box 2. Add Button
3. Configure the following parameters as required:
Parameter Description
IP Address Synopsis: The ipv4-address type represents an IPv4 address in dotted-quad notation.
The IPv4 address may include a zone index, separated by a % sign. The zone index is
used to disambiguate identical address values. For link-local addresses, the zone index
will typically be the interface index number or the name of an interface. If the zone index
is not present, the default zone of the device will be used. The canonical format for the
zone index is the numerical format
The IP address of the network device the entry describes.
4. Click Add. The ARP Table Configuration form appears.
Figure 793: ARP Table Configuration Form
1. MAC Box 2. VLAN ID Box 3. Status List
5. Configure the following parameters as required:
NOTE
Letters in MAC addresses must be lowercase.
