RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Configuring the Destination Zone 403
Figure 441: Source Zone Form
1. Pre-Defined Zone List 2. Other Box 3. All Check Box
3. Configure the following parameter(s) as required:
Parameter Description
predefined-zone A predefined zone
other Type a custom definition - this can be a comma-separated list of zones.
all All zones
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.17.14.4
Configuring the Destination Zone
To configure the destination zone for a firewall rule, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » {firewall} » fwrule{rule} » destintion-zone, where {firewall} is
the name of the firewall and {rule} is the name of the rule. The Destination Zone form appears.
