Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
588 Adding a VRRP Group
Figure 682: VRRP Group Table
If no VRRP groups have been configured, add groups as needed. For more information, refer to Section 5.26.5.2,
“Adding a VRRP Group”.
Section 5.26.5.2
Adding a VRRP Group
To add a VRRP group, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to services » vrrp » group and click <Add group>. The Key Settings form appears.
Figure 683: Key Settings Form
1. Group Name Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Group Name The VRRP group name.
4. Click Add to add the group.
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
Section 5.26.5.3
Deleting a VRRP Group
To delete a VRRP group, do the following:
