494 Adding a Prefix List Distribution Path
Section 5.20.8.2
Adding a Prefix List Distribution Path
To add a prefix list distribution path for dynamic RIP routes, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » rip » distribute-prefix-list and click <Add distribute-prefix-list>. The
Key Settings form appears.
1
3
2
Figure 563: Key Settings Form
1. Direction List 2. Interface Name Box 3. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Direction Synopsis: in, out
Filters incoming or outgoing routing updates.
Interface Name The name of the interface. This parameter is optional.
4. Click Add to add the path. The Distribute Prefix List form appears.
1
Figure 564: Distribute Prefix List Form
1. Prefix List List
5. Configure the following parameter(s) as required:
Parameter Description
Prefix List The name of the prefix list.
