RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Configuring the Connection Ends 631
2. Navigate to tunnel » ipsec » connection » {connection} » esp » algorithm, where {connection} is the
name of the connection. The Algorithm table appears.
Figure 736: Algorithm Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen algorithm.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.28.9
Configuring the Connection Ends
Each IPsec tunnel has two ends: the local router and the remote router. These are otherwise referred to as the
left and right connections, respectively. Both ends can have the same configuration or a unique configuration.
NOTE
The configuration forms for the left and right connection ends are the same.
To configure a connection end for an IPsec tunnel, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to tunnel » ipsec » connection » {connection} » {end}, where {connection} is the name of the
connection and {end} is the either the left (local router) or right (remote router) connection end. The Public IP
Address, System Public Key, System Identifier, Nexthop to Other System and Left/Right forms appear.
