Chapter 4
System Administration
RUGGEDCOM ROX II
User Guide
224 Managing Passwords and Passphrases
Figure 238: Users Screen
1. List of Users 2. Send Button 3. Kick Icon 4. Messages Window 5. Message Box 6. Clear History Button
2. Type a message in the Message box and click Send.
Section 4.10
Managing Passwords and Passphrases
ROX II requires separate passwords or passphrases for logging into the various device modes, such as normal,
boot, service and maintenance modes. Default passwords are configured for each user type initially. It is strongly
recommended that these be changed before the device is commissioned.
For a list of default passwords, refer to Section 2.2, “Default Usernames and Passwords”.
The complexity of each password/passphrase can be chosen by the user or enforced through the device by an
administrator. If a user's password/passphrase does not meet the password requirements, an alarm is generated.
Figure 239: Example – Password Too Short Alarm
