Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
620 Deleting a Pre-Shared Key
Parameter Description
Secret Key Synopsis: The aes-cfb-128-encrypted-string works exactly like des3-cbc-encrypted-
string but AES/128bits in CFB mode is used to encrypt the string. The prefix for
encrypted values is '$4$'.
The pre-shared key.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 5.28.5.3
Deleting a Pre-Shared Key
To delete a pre-shared key, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to tunnel » ipsec » preshared-key. The Preshared Key table appears.
Figure 724: Preshared Key Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen pre-shared key.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.28.6
Managing Connections
An IPsec connection is an encrypted connection between two devices who share the same pre-authorized
authentication key.
The following sections describe how to configure and manage connections for an IPsec connection:
• Section 5.28.6.1, “Viewing a List of Connections”
• Section 5.28.6.2, “Adding a Connection”
