RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding a Pre-Shared Key 619
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to tunnel » ipsec » preshared-key and click <Add preshared-key>. The Key Settings form
appears.
Figure 722: Key Settings Form
1. Remote Address Box 2. Local Address Box 3. Add Button
3. In the Key Settings form, configure the following parameters as required:
Parameter Description
Remote Address Synopsis: any, ,
The remote address.
Local Address Synopsis: any, ,
The local address.
4. Click Add to create the new pre-shared key. The Preshared Key form appears.
Figure 723: Preshared Key Form
1. Secret Key Box
5. In the Preshared Key form, configure the following parameters as required:
