Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
398 Deleting a Masquerade or SNAT Setting
Parameter Description
Outgoing Interface Specifics (Optional) An outgoing interface list - specific IP destinations for the out-interface.
IP Alias Create IP Alias for NAT rule.
Source Hosts Subnet range or comma-separated list of hosts (IPs)
SNAT Address (Optional) By specifying an address here, SNAT will be used and this will be the source
address.
description (Optional) The description string for this masq entry.
7. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
8. Click Exit Transaction or continue making changes.
Section 5.17.13.3
Deleting a Masquerade or SNAT Setting
To delete a masquerade or SNAT setting, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » {firewall} » fwmasq, where {firewall} is the name of the
firewall. The Net Address Translation Main Settings table appears.
Figure 437: Net Address Translation Main Settings Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen masquerade or SNAT setting.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
