RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting a Redistribution Metric 435
Parameter Description
Metric The metric for redistributed routes.
7. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
8. Click Exit Transaction or continue making changes.
Section 5.18.11.3
Deleting a Redistribution Metric
To delete a redistribution metric for an IS-IS area, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » isis » area » {name} » redistribute, where {name} is the unique name for
the area. The Redistribute table appears.
Figure 481: Redistribute Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen metric.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.19
Managing BGP
The Border Gateway Protocol (BGP) as defined by RFC 4271 [http://tools.ietf.org/rfc/rfc4271.txt] is a robust and
scalable routing protocol. BGP is designed to manage a routing table of up to 90000 routes. Therefore, it is used
in large networks or among groups of networks which have common administrative and routing policies. External
BGP (eBGP) is used to exchange routes between different Autonomous Systems (AS). Interior BGP (iBGP) is
used to exchange routes within autonomous system (AS).
BGP is used by the bgpd daemon to handle communications with other routers. The daemon also determines
which routers it prefers to forward traffic to for each known network route.
