Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
434 Adding a Redistribution Metric
Figure 479: Key Settings Form
1. Source List 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
Source Synopsis: bgp, connected, kernel, ospf, rip, static
Protocol that is source of IS-IS information.
5. Click Add to create the new metric. The Redistribute form appears>
Figure 480: Redistribute Form
1. IS-Type List 2. Metric-Type List 3. Metric Box
6. Configure the following parameter(s) as required:
Parameter Description
Routing Type Synopsis: level-1-only, level-2-only, level-1-2
IS type of the IS-IS information, specified as level-1-only, level-2-only or level-1-2. If not
provided, uses IS type from area.
Metric Type Synopsis: internal, external
Default: external
The IS-IS metric type for redistributed routes. Default is external
