754 Viewing Statistics for LLDP Ports
Parameter Description
Chassis ID The Chassis ID information received from a remote Link Layer Discovery Protocol (LLDP)
agent.
Port ID The port ID (MAC) information received from a remote Link Layer Discovery Protocol
(LLDP) agent.
System Name The system name information received from a remote Link Layer Discovery Protocol (LLDP)
agent
System Description The system descriptor information received from a remote Link Layer Discovery Protocol
(LLDP) agent.
Port Description The port description information received from a remote Link Layer Discovery Protocol
(LLDP) agent.
Management Address The management address received from a remote Link Layer Discovery Protocol (LLDP)
agent.
Management Address Interface ID The Management Address Interface ID received from a remote Link Layer Discovery
Protocol (LLDP) agent.
System Capabilities The system capabilities that are advertised for the remote device.
System Capabilities Enabled Enables/disables the System Capabilities feature.
Chassis Subtype Synopsis: chassisComponent, interfaceAlias, portComponent, macAddress,
networkAddress, interfaceName, local
The chassis subtype information received from a remote Link Layer Discovery Protocol
(LLDP) agent.
Port Subtype Synopsis: interfaceAlias, portComponent, macAddress, networkAddress, interfaceName,
agentCircuitId, local
The port subtype information received from a remote Link Layer Discovery Protocol (LLDP)
agent.
Management Address Subtype Synopsis: other, ipV4, ipV6, nsap, hdlc, bbn1822, all802, e163, e164, f69, x121, ipx,
appleTalk, decnetIV, banyanVines, e164withNsap, dns, distinguishedName, asNumber,
xtpOverIpv4, xtpOverIpv6, xtpNativeModeXTP, fibreChannelWWPN, fibreChannelWWNN,
gwid, afi, reserved
The management address subtype received from a remote Link Layer Discovery Protocol
(LLDP) agent.
Management Address Interface Subtype Synopsis: unknown, ifIndex, systemPortNumber
The management address interface subtype received from a remote Link Layer Discovery
Protocol (LLDP) agent.
Time Stamp of Last Change The duration of time between power-on and when this information was received.
Section 5.36.4
Viewing Statistics for LLDP Ports
To view statistics for LLDP ports, navigate to switch » net-discovery » lldp » port-lldp-stats. The LLDP Port
Statistics form appears.
