RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Managing Static Multicast Groups 549
Figure 639: Static Multicast Routing Configuration Form
1. Enabled Check Box
3. Configure the following parameter(s) as required:
Parameter Description
enabled Enables static multicast routing service
Prerequisite: Dynamic and static multicast routing can not be enabled together.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.23.2
Managing Static Multicast Groups
The following sections describe how to configure and manage static multicast groups:
• Section 5.23.2.1, “Viewing a List of Static Multicast Groups”
• Section 5.23.2.2, “Adding a Static Multicast Group”
• Section 5.23.2.3, “Deleting a Static Multicast Group”
Section 5.23.2.1
Viewing a List of Static Multicast Groups
To view a list of static multicast groups, navigate to routing » multicast » static » mcast-groups. If static
multicast groups have been configured, the Multicast Groups Configuration table appears.
Figure 640: Multicast Groups Configuration Table
If no static multicast groups have been configured, add groups as needed. For more information about adding
static multicast groups, refer to Section 5.23.2.2, “Adding a Static Multicast Group”.
