RUGGEDCOM ROX II
User Guide
Chapter 2
Using ROX II
Pinging a Host 23
1. Select the Tools menu and click Accessories.
Figure 10: Tools menu
1. Tools Menu 2. Accessories Menu 3. Ping Menu 4. Ping6 Menu
2. Depending on the host's IP address, click Ping if the host has an IPv4 address, or Ping6 if the host has an
IPv6 address. The Ping screen appears.
Figure 11: Ping Screen
1. New Button 2. Stop Button 3. Current Ping Session List 4. Result Window
3. Click New. The Specify Host dialog box appears.
