RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding an Interface for an IPv4 Static Route 547
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » static » ipv4 » {subnet} » dev, where subnet is the subnet (network/prefix) of the
static route.
3. Click <Add dev>. The Key Settings form appears.
Figure 636: Key Settings Form
1. Interface Name Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
Interface Name The interface for the static route.
5. Click Add to add the interface. The Static Route Using Interface form appears.
Figure 637: Static Route Using Interface Form
1. Distance Box
6. Configure the following parameter(s) as required:
Parameter Description
Distance (optional) The distance for the static route.
7. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
8. Click Exit Transaction or continue making changes.
