Siemens RX1500

RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Configuring a Set 447
1
2
Figure 498: Metric Form
1. Operation List 2. Value Box
1
2
3
4
5
Figure 499: Set Form
1. Local Preference Box 2. Next Hop Box 3. Origin List 4. Originator ID Box 5. Weight Box
3. On the Aggregator form, configure the following parameters as required:
Parameter Description
AS Number AS number.
Prerequisite: as must be empty when ip is not configured.
IP Address IP address of aggregator.
Prerequisite: ip must be empty when as is not configured.
4. On the Metric form, configure the following parameters as required:
Parameter Description
operation Synopsis: set, add, sub
