RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding a Traffic Control Interface 759
2. Navigate to qos » traffic-control » basic-configuration » tcinterfaces, and click <Add tcinterfaces>. The
Key Settings form appears.
Figure 872: Key Settings Form
1. Interface Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
interface An interface to which traffic shaping will apply. Lowercase alphanumerical as well as '.'
and '-' characters are allowed.
4. Click Add to create the new traffic control interface. The Interface to Apply Traffic Control form appears.
Figure 873: Interface to Apply Traffic Control Form
1. Type List 2. Ingress Speed Box 3. Egress Speed Box 4. Unit for Egress Speed List 5. Description Box
5. Configure the following parameter(s) as required:
