RUGGEDCOM ROX II
User Guide
Chapter 3
Device Management
Configuring a Serial Port 117
Figure 119: Serial Interfaces Form
1. Enabled Check Box 2. Alias Box 3. Baud-Rate List 4. Data Bits Box 5. Parity List 6. Stop Bits Box 7. Flow Control List
8. Port Type List
3. Configure the following parameter(s) as required:
Parameter Description
enabled Default: true
Provides the option to enable or disable this interface. When unchecked (i.e disabled),
the interface will prevent all frames from being sent and received on that interface.
alias The SNMP alias name of the interface.
baud-rate Synopsis: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400
Default: 9600
The baud rate selection of the serial port.
data-bits Default: 8
