Siemens RX1500

RUGGEDCOM ROX II
User Guide
Chapter 3
Device Management
Configuring the Raw Socket Protocol 127
1
2
3
4
6
7
5
8
9
10
11
Figure 126: Raw Socket Configuration Form
1. Packet Character Box 2. Packet Timer Box 3. Packet Size Box 4. Turnaround Box 5. Call Direction Box 6. Max
Connection Box 7. Remote IP Box 8. Remote Port Box 9. Local IP Box 10. Local Port Box 11. Transport Box
4. Configure the following parameter(s) as required:
