RUGGEDCOM ROX II
User Guide
Chapter 3
Device Management
Configuring a Frame Relay Connection 169
Figure 178: Frame Relay Parameters Form – CPE Selected
1. Station List 2. Signal List 3. T392 Box 4. N392 Box 5. N393 Box
4. Configure the following parameter(s) as required:
Parameter Description
station Synopsis: cpe, switch
Default: cpe
The behavior of the frame relay connection, i.e. CPE (Customer Premises Equipment)
or as a switch.
signal Synopsis: ansi, lmi, q933, none
Default: ansi
The frame relay link management protocol used.
t391 Default: 10
(Link Integrity Verification polling) Indicates the number of seconds between
transmission of in-channel signaling messages. Valid for cpe.
t392 Default: 16
(Verification of polling cycle) Indicates the expected number of seconds between
reception of in-channel signaling messages transmitted by cpe. Valid for Switch.
n391 Default: 6
