RUGGEDCOM ROX II
User Guide
Chapter 3
Device Management
Adding a Virtual Switch 175
2. Navigate to interface » virtualswitch and click <Add virtualswitch>. The Key Settings form appears.
Figure 184: Key Settings Form
1. Virtual Switch ID Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Virtual Switch ID Virtual switch ID.
4. Click Add to create the new switch. The Virtual Switch form appears.
Figure 185: Virtual Switch Form
1. Enabled Check Box 2. Forward Delay Box 3. Alias Box 4. IP Address Source List 5. ProxyARP Check Box
5. Configure the following parameter(s) as required:
