Chapter 4
System Administration
RUGGEDCOM ROX II
User Guide
194 Configuring an Alarm
Figure 205: Alarm Configuration Form
1. Description Box 2. Severity List 3. Admin Enable Check Box 4. Failrelay Enable Check Box 5. LED Enable Check Box
6. Auto Clear Check Box
3. Configure the following parameters as required:
Parameter Description
description The name of the alarm.
severity Synopsis: emergency, alert, critical, error, warning, notice, info, debug
The severity level can be one of emergency, alert, critical, error, warning, notice, info,
and debug. This cannot be changed for some alarms.
admin-enable If disabled, the alarm is not reported in the active list and does not actuate LED/failrelay.
failrelay-enable If enabled, this alarm will assert the failrelay.
led-enable If enabled, the main 'Alarm' LED light will be red when this alarm is asserted. If disabled,
the main 'Alarm' LED light is not affected by this alarm.
auto-clear If enabled, the LED and failrelay will be cleared automatically when condition is met.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
