Siemens RX1500

RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Configuring an Interface 419
2
1
3
4
5
6
7
8
9
10
11
Figure 458: Interface Parameters Form
1. IPv4 Area Tag Box 2. Circuit Type List 3. Point-to-Point Check Box 4. Passive Check Box 5. Circuit Password Box
6. Circuit Authorization List 7. Metric Box 8. CSNP Interval Box 9. Hello Interval Box 10. Hello Multiplier Box 11. PSNP
Interval Box
3. Configure the following parameter(s) as required:
