Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
498 Adding a Key
Figure 569: Key Settings Form
1. Key ID Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
Key ID The key identifier number.
5. Click Add to add the key chain. The Key Configuration, Accept Life Time and Send Life Time forms
appear.
Figure 570: Key Configuration Form
1. Key Box
Figure 571: Accept Life Time Form
1. Time to Start Box 2. Expire Time Box
