RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding a Route Map Filter Entry 523
Figure 601: Key Settings Form
1. Sequence Number Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
Sequence Number The sequence number of the route-map entry.
5. Click Add to create the new entry. The Route Map Entry and Set forms appear.
Figure 602: Route Map Entry Form
1. Action List 2. Call Route Map List 3. On Match Goto List
