Siemens RX1500

Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
604 Adding a Link Failover Parameter
1
2
3
4
5
6
7
Figure 705: Link Fail Over Settings Form
1. Enabled Check Box 2. Ping Timeout Box 3. Ping Interval Box 4. Ping Retry Box 5. Start Delay Box 6. Main Down Timeout
Box 7. Main Up Timeout Box
5. Configure the following parameter(s) as required:
Parameter Description
enabled Enables this link backup.
ping-timeout Default: 2
The time interval, in seconds, before immediately retrying a ping.
ping-interval Default: 60
The time interval, in seconds, between ping tests.
ping-retry Default: 3
The number of ping retries before constructing a path failure.
start-delay Default: 180
The delay time, in seconds, when first starting link failover.
