Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
640 Configuring L2TP Tunnels
Figure 750: L2TP Form
1. Enable L2TP Check Box 2. Local IP Address Box 3. First IP Address Box 4. Maximum Number of Connections Box
5. Closing Wait Timeout Box
3. On the DNS Server form, configure the following parameter(s) as required:
Parameter Description
Primary The primary DNS server.
Secondary The secondary DNS server.
4. On the WINS Server form, configure the following parameter(s) as required:
Parameter Description
Primary The primary WINS server.
Secondary The secondary WINS server.
5. On the PPP Options form, configure the following parameter(s) as required:
NOTE
If Authorize Locally is not enabled, L2TP will use RADIUS authentication. For more information
about configuring RADIUS authentication for the PPP services, refer to Section 4.8.2, “Configuring
RADIUS Authentication for PPP Services”.
Parameter Description
Authorize Locally Authorizes locally instead of using radius server.
MTU Default: 1410
The Maximum Transmit Unit (MTU) or maximum packet size transmitted.
