Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
54 Adding a Remote Server Selector
Figure 46: Key Settings Form
1. Name Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
name The log selector identifier. Enter an integer greater than 0; up to 8 selectors can be
added. The log selector determines which subsystem messages are included in the log.
5. Click Add. The Remote Server Selector form appears.
Figure 47: Remote Server Selector Form
1. Negate Check Box 2. Comparison List 3. Level List 4. Facility List 5. Add Button
6. Configure the following parameter(s) as required:
