Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
94 Configuring a Switched Ethernet Port
NOTE
Switched Ethernet ports in dedicated routing port mode cannot be trunk ports.
NOTE
The configuration for a switched Ethernet port in switchport mode can be restored when it is
removed from a trunk. However, the configuration cannot be restored if the port is in dedicated
routing mode.
Parameter Description
Enabled Default: true
Provides the option to enable or disable this interface. When unchecked(i.e disabled),
the interface will prevent all frames from being sent and received on that interface.
AutoN Synopsis: on, off
Enables or disables IEEE 802.3 auto-negotiation. Enabling auto-negotiation results in
speed and duplex being negotiated upon link detection; both end devices must be auto-
negotiation compliant for the best possible results.
Speed Synopsis: auto, 1.5M, 2.4M, 10M, 100M, 1G, 10G, 1.776M, 3.072M, 7.2M, 1.2K, 2.4K,
9.6K, 19.2K, 38.4K, 57.6K, 115.2K, 230.4K, 4.8K
Speed (in megabits-per-second or gigabits-per-second). If auto-negotiation is enabled,
this is the speed capability advertised by the auto-negotiation process. If auto-
negotiation is disabled, the port is explicitly forced to this speed mode. AUTO means
advertise all supported speed modes.
Duplex Synopsis: auto, half, full
If auto-negotiation is enabled, this is the duplex capability advertised by the auto-
negotiation process. If auto-negotiation is disabled, the port is explicitly forced to this
duplex mode. AUTO means advertise all supported duplex modes.
Link Alarms Default: true
Disabling link-alarms will prevent alarms and LinkUp and LinkDown SNMP traps from
being sent for that interface. Link alarms may also be controlled for the whole system
under admin / alarm-cfg.
Switchport Sets the physical port into either switched mode or a dedicated routing mode.
Flow Control Flow control is useful for preventing frame loss during times of severe network traffic
on-demand Bring up this interface on-demand only
LFI Link Fault Indication (LFI) is specifically for FX interfaces.
ip-address-src Synopsis: static, dynamic
Whether the IP address is static or dynamically assigned via DHCP or BOOTP. Option
DYNAMIC is a common case of a dynamically assigned IP address. It switches between
BOOTP and DHCP until it gets the response from the relevant server. This must be
static for non-management interfaces.
proxyarp Enables/Disables whether the VLAN will respond to ARP requests for hosts other than
itself
mtu Default: 1500
Maximum transmission unit (largest packet size allowed for this interface).
Alias The SNMP alias name of the interface
4. On the Rate Limiting form, configure the following parameter(s) as required:
