RUGGEDCOM ROX II
User Guide
Chapter 3
Device Management
Configuring a Switched Ethernet Port 95
Parameter Description
Ingress Limit Synopsis: disabled
Default: 1000
The data rate in kbps at which received frames (of the type described by the ingress
frames parameter) will start to be discarded by the switch. The valid range is 62 to
256000 kbps. The default value is 1000 kbps. If not set(cleared), this feature is disabled.
Ingress Frames Synopsis: broadcast, multicast, mcast-flood-ucast, all
Default: broadcast
This parameter specifies the types of frames to rate-limit on this port. It applies only to
received frames:
• BROADCAST : only broadcast frames will be limited.
• MULTICAST : all multicast frames (including broadcast) will be limited.
• MCAST-FLOOD-UCAST : all multicast frames (including broadcast) will be limited.
Unicast will not be limited.
• ALL : all frames (both multicast and unicast) will be limited.
Egress Limit Synopsis: disabled,
Default: disabled
The maximum data rate in kbps at which the switch will transmit (multicast, broadcast
and unicast) frames on this port. The switch will discard frames in order to meet this rate
if required. The valid range is 62 to 256000 Kbps. If not set, this feature is disabled.
5. On the LLDP form, configure the following parameter(s) as required:
Parameter Description
Admin Status Synopsis: tx-only, rx-only, rx-tx, no-lldp
Default: rx-tx
• no-lldp : The local LLDP agent can neither transmit nor receive LLDP frames.
• rxTx : The local LLDP agent can both transmit and receive LLDP frames through the
port.
• txOnly : The local LLDP agent can only transmit LLDP frames.
• rxOnly : The local LLDP agent can only receive LLDP frames.
Notify Disabling notifications will prevent sending notifications and generating alarms for a
particular interface from the LLDP agent.
6. On the Multicast Filtering form, configure the following parameter(s) as required:
Parameter Description
GMRP Synopsis: advertise_only, learn_advertise
GMRP (GARP Multicast Registration Protocol) operation on the port. There are several
GMRP operation modes:
• DISABLED : the port is not capable of any GMRP processing.
• ADVERTISE ONLY : the port will declare all MCAST addresses existing in the switch
(configured or learned) but will not learn any MCAST addresses.
• ADVERTISE and LEARN : the port will declare all MCAST Addresses existing in the
switch (configured or learned) and can dynamically learn MCAST addresses.
7. On the CoS form, configure the following parameter(s) as required:
Parameter Description
Default Priority Default: 0
