Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
98 Configuring Port Security
Figure 100: 802.1x Parameters
1. Transmission Period Box 2. Quiet Period Box 3. Reauthorization Check Box 4. Reauthorize Period Box 5. Reauthorization
Max Attempts Box 6. Supplicant Timeout Box 7. Server Timeout Box 8. Max Requests Box
3. On the Port Security form, configure the following parameter(s) as required:
Parameter Description
Security Mode Synopsis: dot1x_mac_auth, dot1x, per_macaddress, off
Default: off
Enables or disables the security feature for the port. The following port access control
types are available:
• Static MAC address based. With this method, authorized MAC address(es) should be
configured in the static MAC address table. If some MAC addresses are not known in
advance (or which port they are going to reside behind is unknown), there is still an
option to configure the switch to auto-learn a certain number of MAC addresses.
• IEEE 802.1X standard authentication.
