Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
136 Adding an Ethernet Trunk Interface
Figure 139: CoS Form
1. Default Priority Box 2. Inspect TOS Check Box
Figure 140: VLAN Form
1. PVID Box 2. Type List 3. Format List 4. GVRP Mode List
5. On the Ethernet Trunk Interfaces form, configure the following parameter(s) as required:
Parameter Description
Switchport The physical port into either Switched mode or a dedicated Routing mode.
on-demand Bring up this interface on-demand only
ip-address-src Synopsis: static, dynamic
Whether the IP address is static or dynamically assigned via DHCP or BOOTP. Option
DYNAMIC is a common case of a dynamically assigned IP address. It switches between
BOOTP and DHCP until it gets the response from the relevant server. This must be
static for non-management interfaces.
proxyarp Enables/Disables whether the VLAN will respond to ARP requests for hosts other than
itself
