Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
300 Adding a CDMA Profile
Figure 315: Key Settings Form
1. Name Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
name Create a CDMA profile name
4. Click Add to create the new profile. The Cellular Network Configuration and CDMA PPP Configuration
forms appear.
Figure 316: Cellular Network Configuration Form
1. Dial String Box
To Next Page
