Siemens RX1500

Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
414 Adding an Area Tag
2
1
Figure 454: Key Settings Form
1. Area Tag Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Area Tag Name for a routing process, must be unique among router processes for a given router.
Mandatory field.
4. Click Add to create the new area tag. The Area Tag form appears.
