RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding a VRRP Instance 591
Figure 687: VRRP Instance Form
1. VRRP Version 2. Interface List 3. Virtual Router ID Box 4. Priority Box 5. Advertisement Interval Box 6. Gratuitous
ARP Delay Box 7. No Preempt Box 8. Preempt Delay Box 9. Fault to Master Delay Box 10. Use Virtual MAC Check Box
11. VRRP Group List
6. Configure the following parameter(s) as required:
NOTE
A preemption occurs when either:
