Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
642 Configuring L2TPv3 Tunnels
Figure 751: Static L2TPv3 Tunnel Enable Form
1. Enable Check Box
3. Check the Enable check box.
4. Navigate to tunnel » l2tpv3 » static » tunnel and select Add tunnel. The Key Settings form appears.
Figure 752: Key Settings Form
1. Tunnel-Name Field 2. Add Button
On the Key Settings form, configure the following parameter(s) as required:
Parameter Description
tunnel-name Tunnel name, contains any lower case letter or numerical digit.
Prefix 'l2t-' will be added to tunnel name and session name to create l2tpv3 system
interface name (ie. l2tp-1-1)
5. Click Add to create the tunnel. The Static L2TPv3 Tunnels form appears.
