Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
666 Adding a GRE Tunnel
Figure 786: Generic Routing Encapsulation Interfaces Form
1. Local Address Box 2. Remote Address Box 3. Remote Subnet Box 4. MTU Box 5. Multicast Check Box 6. Cost Box
5. Configure the following parameter(s) as required:
Parameter Description
local-ip The IP address of the local end of the tunnel.
remote-ip The IP address of the remote end of the tunnel.
remote-net The target network of the remote end of the tunnel (xxx.xxx.xxx.xxx/xx).
mtu Default: 1476
The MTU of the GRE interface.
multicast Enables multicast traffic on the tunnel interface.
cost Default: 1
The routing cost associated with networking routing that directs traffic through the
tunnel.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
